Porcelain Tile Sizes and Specifications
Choosing the right porcelain tile size affects more than the appearance of a room. It also influences grout-line density, pattern continuity, cutting waste, installation planning, handling requirements and overall project efficiency. Casaferra offers a structured range of porcelain tile sizes for residential, hospitality, retail, commercial and architectural projects.
You can compare formats from 200×1200 mm wood-look planks to 1200×2800 mm porcelain slabs, then review the technical data of each product model before making a final selection. Because thickness, finish, water absorption, slip resistance, wear resistance and packing details vary by product, final specifications should always be confirmed using the relevant product data sheet and test report.
Browse Porcelain Tiles by Size
Casaferra porcelain tile sizes cover modular square formats, rectangular floor and wall tiles, wood-look planks, large-format porcelain tiles and architectural slabs. Select a size below to view the available colors, surfaces, patterns and product models.
600×600 mm Porcelain Tiles
A balanced square format suited to modular layouts and projects that require manageable handling, flexible cutting and efficient installation. It can be considered for residential floors, apartments, offices and selected commercial areas, subject to the performance of the chosen model.
View 600×600 mm Tiles600×1200 mm Porcelain Tiles
A versatile rectangular format that provides greater visual continuity than conventional square tiles. This size is widely considered for floors, wall surfaces, living areas, bathrooms, hotel spaces and commercial interiors.
View 600×1200 mm Tiles200×1200 mm Wood-Look Tiles
A plank-style format developed for wood-look porcelain tile collections. Its elongated proportions can support straight, staggered and other project-approved layouts while creating the visual rhythm of timber flooring.
View 200×1200 mm Tiles1200×1200 mm Porcelain Tiles
A large square format for open residential interiors, hotel spaces, retail environments and commercial floors where fewer grout lines and a broader presentation of the surface pattern are required.
View 1200×1200 mm Tiles750×1500 mm Large-Format Tiles
An elongated large-format option that can enhance stone, limestone and marble-inspired patterns. It is suitable for projects seeking stronger visual continuity across floors, feature walls and large interior surfaces.
View 750×1500 mm Tiles900×1800 mm Porcelain Tiles
An extra-large format designed to reduce the number of visible joints and present more of the original pattern on each tile. It can be considered for villas, hotels, commercial interiors, lobbies and statement wall applications.
View 900×1800 mm Tiles1200×2800 mm Porcelain Slabs
A slab format for full-height wall surfaces, feature walls and other approved architectural applications. Product thickness, support conditions, cutting requirements, installation systems and handling equipment must be confirmed before specification.
View 1200×2800 mm SlabsPorcelain Tile Size Comparison
The following comparison provides a starting point for product selection. It does not replace the technical data of an individual model. Your final decision should also consider substrate conditions, traffic level, slip requirements, cutting plans, installation access and local building regulations.
| Tile Size | Format Type | Visual Character | Common Project Direction | Key Planning Consideration |
|---|
| 600×600 mm | Standard square | Balanced and modular | Residential and selected commercial floors | Layout, joint alignment and cutting efficiency |
| 600×1200 mm | Large rectangle | Fewer joints and stronger direction | Floors, walls and feature areas | Substrate flatness and pattern orientation |
| 200×1200 mm | Porcelain plank | Natural wood-floor proportion | Living spaces, bedrooms and hospitality interiors | Stagger ratio, pattern variation and laying direction |
| 1200×1200 mm | Large square | Open and continuous surface | Large rooms, lobbies and retail spaces | Handling, cutting and installation access |
| 750×1500 mm | Large rectangle | Premium elongated presentation | Large floors, walls and high-end interiors | Substrate preparation and experienced installation |
| 900×1800 mm | Extra-large format | High pattern continuity | Hotels, villas and commercial interiors | Lifting, access, cutting and breakage control |
| 1200×2800 mm | Porcelain slab | Near full-height visual coverage | Feature walls and approved architectural surfaces | Thickness, support, processing and installation system |
Explore Available Looks and Materials
Size is only one part of porcelain tile selection. You can also choose products according to the desired material effect, surface character and overall design direction.
Not every design is produced in every porcelain tile size. Open the relevant collection or contact Casaferra to confirm available combinations of size, color, body, finish and pattern.
How to Choose the Right Porcelain Tile Size
1. Start with the Application
Identify whether the product will be used on a floor, wall, feature surface, bathroom, hospitality area, retail space or another project location. A product should not be approved solely because its dimensions fit the area. Floor applications may require suitable wear and slip performance, while large wall formats require proper assessment of weight, substrate condition and fixing methods.
2. Consider the Size and Shape of the Space
Large-format porcelain tiles can reduce grout-line density and create a more continuous visual field. However, rooms with multiple corners, columns, drains or level changes may require additional cutting and generate more material waste. Review the floor plan before confirming the final format.
3. Match the Format to the Pattern
Marble-look and stone-look designs often benefit from larger formats because more of the vein or mineral pattern remains visible on each tile. Wood-look designs use elongated plank formats to reproduce the direction and scale of timber flooring. Check the number of available faces, shade variation and recommended layout before ordering.
4. Review Site Access and Installation Conditions
Large and extra-large formats require suitable loading access, storage space, lifting equipment, cutting tools and trained installers. Confirm that the tiles can pass through doors, lifts, stairways and corridors before finalizing an order.
5. Plan for Waste and Future Replacement
Ordering quantities should include an appropriate allowance for cutting, pattern alignment, accidental breakage and future maintenance. The required allowance depends on room geometry, laying pattern, product variation and installation method rather than tile size alone.
6. Confirm the Exact Product Specification
Two products with the same nominal dimensions may have different thicknesses, surfaces, bodies, slip ratings, wear classifications or packaging details. Always approve the exact item code, sample and technical document before mass ordering.
Technical Information to Confirm Before Ordering
For distributors, contractors, architects and project buyers, a complete quotation should identify more than the nominal tile size. The following fields help reduce misunderstandings during sampling, purchasing, installation and later replenishment.
| Specification | Why It Matters | What You Should Confirm |
|---|
| Nominal and actual size | Supports layout and joint planning | Production caliber, dimensional tolerance and batch consistency |
| Thickness | Affects weight, handling and installation | Actual thickness of the selected item code |
| Edge type | Influences grout width and visual continuity | Whether the model is rectified or uses another edge treatment |
| Surface finish | Affects appearance, touch, cleaning and application | Matte, polished, textured, moulded or another available finish |
| Water absorption | Helps define the ceramic body and performance direction | Declared value and supporting test document for the model |
| Slip resistance | Important for floors, entrances and wet areas | Applicable rating, test method and intended use |
| Wear resistance | Important for traffic-bearing glazed surfaces | Declared class and suitability for the planned traffic level |
| Pattern faces | Controls visual repetition across large areas | Number of faces and recommended laying arrangement |
| Shade variation | Affects the final appearance of the installed surface | Expected variation and sample approval method |
| Packing details | Supports landed-cost and loading calculations | Pieces, square metres and weight per carton and pallet |
Technical values are model-specific. Please refer to the individual product page, approved sample and formal test report rather than using a value from another product in the same size.
Browse Casaferra Products by Specification
Use the size categories above or browse the available products below. Each product card should lead to a detail page showing the item code, color, nominal size, surface craft, number of pattern faces and available technical information.
Porcelain Tile Size Selection by Project Type
| Project Area | Possible Format Direction | Main Specifications to Review |
|---|
| Residential living areas | 600×600, 600×1200 or large square formats | Finish, shade variation, wear performance and layout |
| Hotel lobbies and public interiors | Large and extra-large formats | Traffic suitability, slip performance, batch consistency and replacement supply |
| Bathroom walls | Rectangular formats or approved slabs | Weight, substrate, fixing system, cleaning and joint arrangement |
| Bathroom floors | Selected according to drainage and layout | Slip resistance, slope formation, cuts and grout joints |
| Retail and commercial floors | Medium, large or modular formats | Wear resistance, cleaning requirements, traffic and maintenance access |
| Feature walls | 600×1200, large format or approved slab formats | Pattern continuity, weight, edge treatment and installation access |
| Wood-look floors | 200×1200 mm plank format | Pattern faces, stagger ratio, laying direction and joint width |
| Large architectural surfaces | 900×1800 or 1200×2800 mm | Handling, cutting, support, transport and specialist installation |
These directions are intended for preliminary comparison only. Final product suitability must be based on the technical data and installation conditions of the selected model.
You can also review Casaferra’s completed spaces on the tile projects page or discuss application-specific requirements through our custom tile solutions service.
Custom Specifications and Project Supply
When a standard product does not fully match your project, Casaferra can evaluate customized porcelain tile requirements based on your target quantity, application and design brief. Available project discussions may cover:
Size and thickness requirements;
Color matching and tone adjustment;
Pattern and texture development;
Surface process selection;
Body and water-absorption requirements;
Custom labels, cartons and project packaging;
Sample development and approval;
Wholesale, distribution and project supply planning.
Custom feasibility, minimum order quantity, sample time, production schedule and pricing depend on the requested specification. Review the complete process on the Casaferra custom tile solutions page.
Information to Include in Your Request
Preferred product or collection;
Required tile size and thickness;
Surface finish and intended application;
Estimated order quantity;
Project location and destination port;
Required delivery schedule;
Packing, labeling or private-label requirements;
Applicable test reports or project standards.
Providing this information helps the Casaferra team recommend a suitable existing product or evaluate a customized specification more efficiently.
Request Technical and Purchasing Documents
Depending on the selected product and project stage, you may request available documentation to support selection, approval and procurement, including:
Product catalogue and collection brochure;
Product specification sheet;
Available test reports;
Packing and loading information;
High-resolution product images;
Surface samples and color references;
Project quotation and customization proposal.
For company and manufacturing information, visit About Casaferra. For product documents, samples or quotations, submit your requirements through the contact page.
Frequently Asked Questions About Porcelain Tile Sizes
What porcelain tile sizes does Casaferra offer?
The current size categories include 600×600 mm, 600×1200 mm, 200×1200 mm, 1200×1200 mm, 750×1500 mm, 900×1800 mm and 1200×2800 mm. Product availability differs by collection, color and surface.
Which porcelain tile size is best for commercial floors?
There is no single size suitable for every commercial project. You should consider traffic, slip resistance, wear performance, substrate condition, maintenance requirements, installation access and layout before selecting the format.
Can large-format porcelain tiles be installed on walls?
Certain large-format products may be considered for wall installation, but suitability depends on the product thickness, weight, substrate, fixing system and site conditions. Technical and installation approval is required.
What is the difference between nominal and actual tile size?
Nominal size is the general commercial format used to identify a product. Actual production dimensions and caliber information should be confirmed through the technical documentation and approved batch information.
Are all Casaferra porcelain tiles the same thickness?
No. Thickness can vary according to size, collection, body and intended application. Confirm the thickness of the specific item code rather than applying one value to every product.
Can I order a customized porcelain tile size?
Casaferra can evaluate custom dimensions and related product requirements according to the design, quantity, body, surface and production feasibility. Custom MOQ, sample cost and lead time are confirmed after technical review.
Can different sizes or collections be combined in one order?
Mixed-product purchasing may be evaluated according to the selected products, quantities, packing method and loading plan. Submit your complete order list for confirmation before placing an order.
How do I obtain samples and technical data?
Send Casaferra the product code, required size, finish, quantity, application and destination. The team can then confirm available samples, documents and quotation information.
Should I select a tile based only on its size?
No. Size should be reviewed together with thickness, finish, water absorption, slip resistance, wear performance, pattern faces, packing and installation conditions.
Find the Right Porcelain Tile Specification for Your Project
Share your application, preferred design, required size, quantity and project schedule with Casaferra. Our team will help you review suitable collections, technical information, samples and customization options before you finalize your purchase.
